Inkjet Writer
The inkjet writer comes in four variants with 1, 7, 16 or 32 nozzles that provide multipurpose waterproof marking fit for industrial environment. Depending on the version, it can write lines, Cyrillic and Latin characters, barcodes or 2D matrix codes. Apart from Y and Z axes, the tool station has a rotary Z axis enabling it to mark lines with different thicknesses and texts of different sizes. The marking speed reaches respectable 20 m/min.
Technical parameters
| Number of nozzles | 1 | 7 | 16 | 32 |
|---|---|---|---|---|
| Marking | lines | lines, single-line text | lines, one- to two-line text | lines, one- to four-line text |
| Line thickness | 1 – 2 mm | 1 – 2 mm | 1 – 2 mm | 1 – 2 mm |
| Text height per line | no text marking | 10 – 28 mm | 10 – 60 mm | 10 – 128 mm |
| Barcode / Matrix | no code marking | no code marking | no code marking | barcode CODE39 2D data matrix ECC 200 |
Achievement of the best legibility and printing quality largely depends on selection of the most suitable ink for any given application. A number of factors must be considered, including the printing surface qualities (porous or non-porous, smooth or rough surfaces, absorption rate etc.), the environment (dusty area, high ambient temperatures etc.) and expected drying times.
| Number of nozzles | 1 | 7 | 16 | 32 |
|---|---|---|---|---|
| Marking | lines | lines, single-line text | lines, one- to two-line text | lines, one- to four-line text |
| Line thickness | 3⁄64 – 5⁄64 in | 3⁄64 – 5⁄64 in | 3⁄64 – 5⁄64 in | 3⁄64 – 5⁄64 in |
| Text height per line | no text marking | 25⁄64 – 1 7⁄64 in | 25⁄64 – 2 23⁄64 in | 25⁄64 – 5 3⁄64 in |
| Barcode / Matrix | no code marking | no code marking | no code marking | barcode CODE39 2D data matrix ECC 200 |
Achievement of the best legibility and printing quality largely depends on selection of the most suitable ink for any given application. A number of factors must be considered, including the printing surface qualities (porous or non-porous, smooth or rough surfaces, absorption rate etc.), the environment (dusty area, high ambient temperatures etc.) and expected drying times.
